1.Stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system.
2. Production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety.
3. Servo transmission system, high positioning accuracy, fast speed, good stability and reliability.
4. Suitable for flexible production of small quantity and various bottle shape,wide range of applications,meet customer needs.
5. Increase energy using efficiency,increase productivity per unit of time.
6. Manual and automatic methods of operation, human-machine interface control, simple operation.
7. Servo transmission system, high positioning accuracy, fast speed stability and good reliability.
8. Safety self-locking device in each mechanical action,when a certain process fails, the program will automatically switch to a safe state.
9. Less than 0.2% scrap rate for finished bottle .
The main technical parameters
|
General Information |
SMC-5000 4 cavity |
|
Clamping Force |
40T |
|
Clamping Stroke |
125mm |
|
Max.Stretching Stroke |
400mm |
|
Bottle Moving Stroke |
0-50mm |
|
Cavity No. |
4cavity |
|
Output |
4000-5000BPH |
|
Max.Mould Thickness |
300mm |
|
Space Between Tie Bars |
100mm |
|
Mould Plate Size |
670x650mm |
|
High Pressure Air compressor |
4.8m³/min 3.0Mpa |
|
Low Pressure Air compressor |
1.6m³/min 1.0Mpa |
|
Voltage Standard |
380V/3PH/50Hz |
|
Heating Zone No. |
4 Sections |
|
Total Power |
50KW |
|
Bottle Volume |
0.1-2.0L |
|
Neck Diameter Range |
16-38mm |
|
Max.Bottle Diameter |
115mm |
|
Bottle Height |
360mm |
|
High-Pressure System |
3.0-4.0Mpa |
|
Low-Pressure System |
0.8-1.0Mpa |
|
Machine Size |
355x160x200cm |
|
Auto-loader |
110x120x220cm |
|
Net Weight |
3.8T |
